The Handling Materials and Application of Rotary Dryer:
Rotary dryer can dry various kind of materials which contain moisture, such as coal, coal slurry, slag, industrial waste, and clay stone Widely used in building materials, metallurgy, and chemical industry.
The Inner Structure of Rotary Dryer:
Rotary dryer consists of the main drum and some other parts. The outer motor drives the big gear and then the dry works. The inside structure includes lifting type, screw type and separated type. The heating method includes downstream, upstream and middle heating.
The Advantages and Benefits of Rotary Dryer:
- Large production capability, continuous operation.
- Simple structure, convenient operation.
- Low malfunction, low maintenance cost.
What can you get?
Latest Price List/Free Customized Solution/Maintenance & Installation Guide
-
Free customized solutions
Customize different models according to your needs（Small, medium, and large machine）.
-
Factory direct sales
We have three production bases, guarantee 100% factory price of all products, and support export to
all over the world.
-
24-hour online service
We have professional customer service staff, ready to answer your questions about our products.
Technical Parameter
|
Spec./m
(Dia.×Length）
|
Shell Cubage
（m³）
|
Capacity
（t/h）
|
Installation
Obliquity
（%）
|
Highest Inlet
Air Temperature
（℃）
|
Main Motor
（kw)
|
Weight
（t）
|
|
Φ1.2×8.0
|
9.0
|
1.9～2.4
|
3～5
|
700～800
|
7.5
|
9
|
|
Φ1.2×10
|
11.3
|
2.4～3.0
|
3～5
|
700～800
|
7.5
|
11
|
|
Φ1.5×12
|
21.2
|
4.5～5.7
|
3～5
|
700～800
|
15
|
18.5
|
|
Φ1.5×14
|
24.7
|
5.3～6.6
|
3～5
|
700～800
|
15
|
19.7
|
|
Φ1.5×15
|
26.5
|
5.7～7.1
|
3～5
|
700～800
|
15
|
20.5
|
|
Φ1.8×12
|
30.5
|
6.5～8.1
|
3～5
|
700～800
|
18.5
|
21.5
|
|
Φ1.8×14
|
35.6
|
7.6～9.5
|
3～5
|
700～800
|
18.5
|
23
|
|
Φ2.2×12
|
45.6
|
9.7～12.2
|
3～5
|
700～800
|
22
|
33.5
|
|
Φ2.2×14
|
53.2
|
11.4～14.2
|
3～5
|
700～800
|
22
|
36
|
|
Φ2.2×16
|
60.8
|
13.0～16.2
|
3～5
|
700～800
|
22
|
38
|
|
Φ2.4×14
|
63.3
|
13.5～16.9
|
3～5
|
700～800
|
37
|
45
|
|
Φ2.4×18
|
81.4
|
17.4～21.7
|
3～5
|
700～800
|
37
|
49
|
|
Φ2.4×20
|
90.4
|
19.3～24.1
|
3～5
|
700～800
|
45
|
54
|
|
Φ2.4×22
|
99.5
|
21.2～26.5
|
3～5
|
700～800
|
45
|
58
|
|
Φ2.6×24
|
127.4
|
27.2～34.0
|
3～5
|
700～800
|
55
|
73
|
|
Φ3.0×20
|
141.3
|
30.1～37.7
|
3～5
|
700～800
|
75
|
85
|
|
Φ3.0×25
|
176.6
|
37.7～47.1
|
3～5
|
700～800
|
75
|
95
|
|
Φ3.2×25
|
201
|
42.9～53.6
|
3～5
|
700～800
|
90
|
110
|
|
Φ3.6×28
|
285
|
60.8～76.0
|
3～5
|
700～800
|
160
|
135
|
Technical parameters of indirect heat dryer:
Shell
diameter
×shell
Length
Items |
Inside
diameter
of outer
shell
（mm） |
Inside
diameter
of inner
shell
（mm） |
Shell
Length
（m） |
Shell
cubage
（m³） |
Shell
obliquity |
Lifting
blade
form |
Highest
inlet air
temperature
（℃） |
Dimensions
（m） |
| Φ1.5×15m |
1500 |
500 |
15 |
20.27 |
3-5% |
Lifting form |
850 |
16.2×2.7×2.7 |
| Φ1.5×17m |
17 |
22.97 |
18.2×2.7×2.7 |
| Φ1.5×19m |
19 |
25.68 |
20.0×2.9×2.9 |
| Φ1.8×21m |
1800 |
650 |
21 |
35.91 |
3-5% |
Lifting form |
850 |
22.5×2.7×2.7 |
| Φ1.8×23m |
23 |
39.33 |
24.5×2.9×2.9 |
| Φ1.8×25m |
25 |
42.75 |
26.5×2.9×2.9 |
| Φ2.2×21m |
2200 |
800 |
21 |
58.10 |
3-5% |
Lifting form |
850 |
---- |
| Φ2.2×23m |
23 |
63.61 |
| Φ2.2×25m |
25 |
69.15 |
Note:processing Capacity May Vary With Different Materisla Aan Feeding Sizes.
